SPECIFICATIONS

• FRAME

  Unidirectional Carbon Fiber Front Triangle, Series 4 Alloy Rear End, 29” Wheels, 150mm Travel MultiTrac Suspension Platform, Internal Dropper Post and Rear Derailleur Housing, Chainstay Mounted Post Mount Disc Brake, 148x12mm Boost Thru- Axle, 73mm Threaded BB w/ ISCG05 Tabs

• FORK

  Fox 38 Performance Elite, 160mm Travel, 29" , 110x15mm Boost Kabolt Thru-Axle, 44mm Offset, Integrated Fox Fender

• REAR SHOCK

  Fox Float X, Performance, EVOL Air Spring, 3 Position Compression Adjustment, Rebound Adjustment, 205x65mm, Trunnion Upper Mount, 25mmxM8 Lower Mount

• RIMS

  Marin, Double Wall Alloy, 29mm Inner, Welded Joint, Disc Specific, 32H, Tubeless Compatible

• HUB REAR

  Forged Aluminum, 148x12mm, Disc, Microspline Freehub Body

• HUB FRONT

  Forged Aluminum, 110x15mm, Disc

• SPOKE

  14g Black Stainless Steel

• TIRES

  Maxxis Assegai 29x2.5”, Tubeless Compatible

• DERAILLEUR REAR

  Shimano SLX 12-Speed, SGS

• DERAILLEUR FRONT

  -

• SHIFT LEVER

  Shimano SLX 12-Speed, SL-7100

• CRANKSET

  FSA Gradient, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, MegaExo Spindle, Boost Spacing

• BOTTOM BRACKET

  MegaEvo BB, 73mm BSA Threaded

• CHAIN

  KMC X-12 Silver and Black

• CASSETTE

  Shimano, Deore M6100 12-Speed, 10-51T

• BRAKE FRONT

  Shimano SLX, 4-Piston Hydraulic Disc, 203mm Rotor

• BRAKE REAR

  Shimano SLX, 4-Piston Hydraulic Disc, 180mm Rotor

• BRAKE LEVERS

  Shimano SLX Hydraulic, I-Spec EV

• HANDLEBAR

  Marin Trail, 35mm Clamp, 7000 Alloy Bar, 800mm Length, 20mm Rise, 5 Degree Up, 8 Degree Back

• STEM

  Marin CNC, 35mm Length, 35mm Bar Bore

• GRIPS

  Marin Single Clamp Locking

• HEADSET

  FSA No 57, Sealed Cartridge Bearings, 1 1/8" x 1 1/2”

• SEATPOST

  X-Fusion Manic, 1x Shimano I-Spec EV Remote, Size S 125mm Travel, Size M and L 150mm Travel, Size XL 170mm Travel, 30.9mm

• SADDLE

  Marin Trail Speed Concept Pro

• PEDALS

  -

• EXTRAS

  Bolt-On Thru-Axle
